What is Flake Glass and What is it Used For?

Glass flakes are engineered glass nanoparticles, shaped similar to a platelet. The glass flakes possess an ability to overlap and form an extremely thin, multilayered glass barrier within your coating. This thin, multilayered glass barrier, composed of flakes, creates a tortuous path for any MVT (moisture/vapor transmission). The benefits do not stop with reduced risk of MVT, as our flakes have also been found to provide improved abrasion resistance, help prevent chipping in high impact zones, and more. Are you looking for a high performance additive to take your coating to the next level?

Ameriflake glass products are 100% Made in America and are infinitely versatile materials with expanding potential for application in a diverse range of industries. Flake glass is offered for use in many applications, the most common of which include:

  • Anti-corrosion coatings in chemical plants
  • Coatings used in heated brine storage tanks
  • Various coatings used in salt water environments
  • Liners for water tanks, boilers, floor linings, fish tanks, silos, petroleum tanks, marine cooling pipes
  • Substrates for decorative or cosmetic products

When properly used, glass flakes have been shown to increase the chemical resistance of coatings, improve the dimensional stability of moldings, reduce surface waviness, and provide a unique substrate for pigment deposition. New uses for glass flakes are still being found thanks to their unique ability to be engineered to a wide range of specifications.

Manual

Learn More

Special Effects

Learn More

Multipurpose

Learn More

Spray

Learn More

Glass flakes are the premier high performance additive in the coatings industry.

Here at Ameriflake Glass, we provide a line of glass flake products that have been proven to improve the durability and lifespan of your coating. Do you have surfaces exposed to extreme wear? Do you have an area prone to chemical attack? Our products have been tested in some of the harshest environments imaginable and have been proven to outlast other fillers. Is your current coating cracking and peeling from being exposed to agents of corrosion or extreme conditions? If so, the addition of glass flake to your coating may be your solution. We offer a range of particle sizes shown in the table below that can be added to both trowel application type coatings and spray application type coatings. We also offer various silane treatments to help the flake glass couple with your resin. Please contact us today to speak with an expert about glass flake.

Our Products

Product Designation Nominal Flake Thickness (Microns) Bulk Density (lbs/ft3) Particle Size Distribution (Microns) Surface Treatment Packaging lb (kg)
ACF-100 5 ± 1 26 ± 5 < 150 (0-20%)
150-300(10-50%)
300-710 (30-60%)
710-1700 (0-30%)>1700(0%)
None Kraft bag 44lb (20kg)
ACFT*-100 5 ± 1 26 ± 5 Same as ACF-100 Silane see below Sams as ACF-100
ACF-200 5 ± 1 42 ± 5 < 106 (20-50%)
106-150(10-30%)
150-300 (15-45%)
300-710 (0-10%)>710(0%)
None Kraft bag 44lb (20kg)
ACFT*-200 5 ± 1 42 ± 5 Same as ACF-200 Silane see below Same as ACF-200
ACF-300 5 ± 1 55 ± 5 < 45 (70-100%)
45-53(0-30%)
>53(0%)
None Kraft bag 44lb (20kg)
ACFT*-300 5 ± 1 55 ± 5 Same as ACF-300 Silane see below Same as ACF-300

*Resin Compatibility of Standard Treatments T1 – Polyurethane: T2 – Vinylester: T3 – Epoxy: T4 – Polyester.
Glass composition may vary slightly from batch to batch. *This information is given in good faith without guarantees or liability. All values are approximate

Customer Resource: Safety Data Sheet PDF


In addition, tailored silane treatments may be specified. Ameriflake prides itself on the ability to custom engineer its flake products via manipulations of flake composition, flake physical dimensions, and/or flake surface treatment. Let the Ameriflake staff know of your special needs.

Trusted by Companies Around the Globe

Contact Ameriflake today to learn more about our products, our processes, and how you can partner with a high-quality, American-made flake glass manufacturer. Our experienced staff is ready to help with expert advice, flake glass samples, technical inquiries and more! Contact Ameriflake Today.
